HAFELE INVISIBLE HINGE 3D Adj Conc.Hinge 60kg (L)
RM181.0
Door leaf width max.
1,000.00 mm
Flap shape
rounded
Flap width
29 mm
Material
Zinc Die Casting
Flap height
111.5 mm
Application
for wooden frames,
for non-rebated wooden interior doors
for wing type
Wooden grand piano
for frame type
Wooden frame
Beam angle
180,00 °
Door leaf height max.
2,000.00 mm
Door thickness
≥40 mm
Adjustment
Three-dimensional stepless, side: ±1 mm, height: ±1.5 mm, pressure: ±1 mm
